Symbol Parameter Value Unit

VS Supply Voltage 30 V

V1,V2 Flyback Peak Voltage 65 V

V3 Trigger Input Voltage 20 V

V8 Amplifier Input Voltage GNDtoVS V

I0 Output Peak to Peak Current (non repetitive t = 2ms) 6 A

I0 Output Peak to Peak Current t > 10?s 4 A

I10 Pin 10 DC Current at V1 < V9 100 mA

I10 Pin 10 Peak to Peak Current @ tfly < 1.5ms 3 A

Ptot Total Power Dissipation @ Ttab = 60?C 9 W

TS,TJ Storage and Junction Temperature - 40, + 150 ?C
