HIGH OUTPUT POWER CAPABILITY

2 x 38W/4? @18V, 1KHz, 10%

4 x 11W/4? @18V, 1KHz, 10%

2 x 20W/8? @18V; 1KHz, 10%

4 x 13W/2? @15V, 1KHz, 10%

2 x 34W/8? @ 22V, 1kHz, 10%

? MINIMUM EXTERNAL COMPONENTS

COUNT:

? NO BOOTSTRAP CAPACITORS

? NO BOUCHEROT CELLS

? INTERNALLY FIXED GAIN (26dB BTL)

? ST-BY FUNCTION (CMOS COMPATIBLE)

? NO AUDIBLE POP DURING ST-BY

OPERATIONS

? DIAGNOSTIC FACILITIES

? CLIP DETECTOR

? OUT TO GND SHORT

? OUT TO VS SHORT

? SOFT SHORT AT TURN-ON

? THERMAL SHUTDOWN PROXIMITY

Protections:

? OUPUT AC/DC SHORT CIRCUIT

? TO GND

? TO VS

? ACROSS THE LOAD

? SOFT SHORT AT TURN-ON

? OVERRATING CHIP TEMPERATURE WITH

SOFT THERMAL LIMITER

? FORTUITOUS OPEN GND

? REVERSED BATTERY

? ESD
